Santa Elena Silver / Gold Mine



Overview

The Santa Elena Silver / Gold Mine is 100% owned by First Majestic Silver Corp. and is comprised of mining concessions that totals 51,172 hectares. The Santa Elena operation involves combined processing of ore from the remaining reserves in the open pit, updated reserves from underground development and reprocessing of spent ore from the existing heap leach pad.

The mine was successfully transitioned from an open pit heap leach operation to an underground mining and milling operation. Commercial production for the 3,000 tonne per day processing plant was declared on August 1, 2014.

Location

The Santa Elena mine site is approximately 150 km northeast of the state capital city of Hermosillo, Sonora, Mexico near the intersection of 30º 01' north latitude, and 110º 09' west longitude.

Mining & Milling Operations

Currently the Company is mining on three stopes in order to reach and maintain 1,750 tonnes per day of underground production. Concurrently the leach pads are being reprocessed to ensure throughput tonnages at 3,000 tonnes per day through the mill. Mill recoveries are targeted at 90% for Gold and 85% for Silver, with annual production projected to range from 5.4 million to 6.0 million silver equivalent ounces.

Operating Highlights



Santa Elena Production Results 2015 - Q4 2014
Ore Processed/Tonnes Milled and Leached 254,625 739,542
Average Silver Grade (g/tonne) 96 74
Silver Recovery (%) 86% 66%
Total Silver Ounces Produced 673,969 1,157,021
Gold Ounces Produced 11,110 27,609
Average Gold Grade (g/tonne) 1.47 1.03
Gold Recovery (%) 92% 90%
Total Production - Ounces Silver Equivalent 1,506,405 2,813,559
Underground Development (m) 1,738 4,483

Local Geology, Mineralization & Ore Types

Santa Elena is located in the Basin and Range Province, which is part of the Sonora Desert subprovince. The region is near the Proterozoic rifted continental margin of the North American plate, which was the site of deposition of a thick sequence of shallow marine shelf carbonate and siliclastic rocks. Subduction of the Farallon Plate beneath the North American Plate during Jurassic time resulted in continental volcanism. In late Jurassic time, a northwest-trending rift basin formed which was the site of sedimentation and felsic and intermediate volcanism.

Locally, the primary rock types are early Tertiary andesite and rhyolite flows which exhibit propylitic to silicic alteration. The main mineralized zone is a cross-cutting structure trending approximately east-west and dipping about 45° to the south. Alteration is widespread and pervasive with significant silicification, kaolinization and chloritization. Gangue minerals consist of quartz, calcite, chlorite and fluorite.

The Santa Elena deposit is considered to be high calcium, low-sulfidation type with replacements, stockworks and hydrothermal breccias similar to other high level low-sulfidation deposits found in Mexico, Chile and Nevada and Arizona in the United States.

For more detailed geological information readers are encouraged to review the Company's most recent NI 43-101Technical Report (PDF).

The Reserves/Resources inventories are reported in NI 43-101 Technical Reports published periodically by the Company. The complete report can be viewed in the Reserves/Resources section or on SEDAR



Maps

Long Section of El Cholugo Plan (Looking North)


Long Section of El Cholug…
3D Looking South


3D Looking South
600 Level U/G Face Channel Sampling (Looking West) April 2015


600 Level U/G Face Channe…
